RGBIC Triangle
LED Strip · DC48V 90px
DC48V Long-Run RGB Pixel LED Strip
Long-distance Without Voltage Drop DC48V Addressable LED Strip 90LEDs/m RGB/RGBW for Architectural Lighting
Individually addressable full-color LED strip for pixel-mapped accent, contour and signage runs.
- Certification
- CE · ROHS · BIS
- MOQ
- 1 piece
- Delivery
- 5–7 days
- Warranty
- 2 years
Reply within 8 hours · Free sample for qualified projects
Overview
About the DC48V Long-Run RGB Pixel LED Strip
DC48V Long-Run RGB Pixel LED Strip is an addressable full-color LED strip built on SMD5050 emitters at 90LED/M. Each LED is individually addressable, so the strip drives pixel-mapped wash, chase and contour effects.
Control is over standard SPI. It runs on DC48V. A 120 Degree beam angle gives an even spread across the run.
It ships in IP20/IP65 and links end-to-end for longer runs. Expect a rated life of 50000 Hours.
Highlighted features
- Individually addressable pixels for full pixel-mapping and video effects
- Smooth colour mixing and dimming
- IP20/IP65 sealing for outdoor and wet-location use
- Cuttable and end-to-end linkable
- 120 Degree beam angle for even, wide coverage
Technical parameters
- Led
- SMD5050
- Voltage
- DC48V
- Ip Rating
- IP20/IP65
- Beam Angle
- 120 Degree
- Number Of Leds
- 90LED/M
- Lamp Power
- 21.6w/m
- Material
- FPC
- Working Lifetime
- 50000 Hours
- Dimension
- 5000*10mm
Model DC48V 90px — configurable per order. Request the full datasheet.
- Payment
- T/T
- Supply
- Large factory stock
- Origin
- Shenzhen, China
- OEM / ODM
- Welcome
Built for these venues.
OEM & ODM — built to your spec.
Cut-to-length: fixtures are built to the run length your project needs.
Driver IC selection to match your controller ecosystem.
Control protocol configurable to your rig.
Ingress protection: IP20/IP65.
