PI-10060ICRGB-50
LED Strip · PI-10060ICRGB-50S
10mm Addressable RGB LED Strip
FW1934/TM1934 60LEDs/m RGB Digital Smart Strip Light Black PCB 20IC/m IP20 Pixel LED Strip Light for Decorative Lighting
Individually addressable full-color RGB LED strip for addressable accent and contour lighting.
- Certification
- CE · ROHS · BIS
- MOQ
- 1 piece
- Delivery
- 5–7 days
- Warranty
- 2 years
Reply within 8 hours · Free sample for qualified projects
Overview
About the 10mm Addressable RGB LED Strip
10mm RGB LED Strip (PI-10060ICRGB-50S) is a full-color RGB LED strip built on SMD5050 emitters, with 60 LEDs/m. Each LED is individually addressable, so the fixture drives addressable accent runs, contour lighting and pixel-mapped surfaces.
Control is over RF, WIFI or APP, with WS2811, SM16703 or TM1934 driver ICs. A 120° beam angle gives an even spread across the run.
It is cuttable every 3 LEDs and links end-to-end for longer runs. Expect a rated life of 50,000 Hours.
Highlighted features
- Individually addressable pixels for full pixel-mapping and video effects
- RGB colour mixing with smooth dimming and gradients
- Cuttable and end-to-end linkable for made-to-length runs
- 120° beam angle for even, wide coverage
- Long 50,000 Hours rated lifespan
Technical parameters
- LED Type
- SMD5050
- Color
- IC RGB
- Driver IC
- WS2811, SM16703, TM1934
- Control Mode
- RF/WIFI/APP
- LED Quantity
- 60/LEDs/M
- Beam Angle
- 120°
- Size
- L5000*W10mm
- Cutting Unit
- 3LED
- Working Temperature
- -20℃~50℃
- Lifespan
- 50,000 Hours
Model PI-10060ICRGB-50S — configurable per order. Request the full datasheet.
- Payment
- T/T
- Supply
- Large factory stock
- Origin
- Shenzhen, China
- OEM / ODM
- Welcome
Built for these venues.
OEM & ODM — built to your spec.
Cut-to-length: fixtures are built to the run length your project needs.
Driver IC selection: WS2811, SM16703, TM1934 to match your controller ecosystem.
Control protocol: configurable for RF, WIFI, APP.
