SK6812 RGBW Addressable LED Strip
SK6812 RGBW Addressable LED Strip — 5V
5V RGBW addressable LED strip with a 4-in-1 emitter. Select white color temperature and sealing configuration when ordering.
- Certification
- CE · ROHS · BIS
- MOQ
- 1 piece
- Delivery
- 5–7 days
- Warranty
- 2 years
Reply within 8 hours · Free sample for qualified projects
Overview
Engineered for the real install.
This product page covers the supplier’s 5V RGBW configuration with a 4-in-1 emitter. White color temperature can be selected for the order; this is not a claim of dynamically tunable white. The related 12V RGB supply is a different configuration, not a 12V option for this same RGBW strip.
The supplier lists these sealing configurations: bare PCB IP20, surface coating IP65, hollow sleeve IP66 and solid, fully filled sleeve IP68. Select the actual supplied assembly, including connector and end sealing; these are this supplier’s options, not a universal construction-to-IP standard.
Confirm the LED density, cutting unit, LEDs per controllable pixel and controller wiring for the ordered version. Choose the required resolution and cut lengths together with the model-specific pixel grouping.
Highlighted features
- RGBW
- DC5V
- 4-in-1 emitter; white color temperature selected at order
- Sealing configuration selected for the supplied assembly
Technical parameters
- Size
- L5000*W10mm
- Color
- RGBW
- Cutting Unit
- Confirm for the selected configuration
- LED Type
- SMD5050
- Beam Angle
- 120°
- Lifespan
- 50,000 Hours
- Working Temperature
- -20℃~50℃
- Voltage
- DC5V (RGBW)
- Control Mode
- Confirm for the selected configuration
- LED Quantity
- 30/60 LEDs/m — confirm configuration
- IP Grade
- IP20 / IP65 / IP66 / IP68
- Bare PCB
- IP20
- Surface coating
- IP65
- Hollow sleeve
- IP66
- Solid, fully filled sleeve
- IP68
Representative specs — configurable per order. Request the full datasheet.
- Payment
- T/T
- Supply
- Large factory stock
- Origin
- Shenzhen, China
- OEM / ODM
- Welcome
Built for these venues.
OEM & ODM — built to your spec.
Specify 5V RGBW, white color temperature, sealing, run lengths and controller. Confirm density, cutting and pixel grouping on the exact supplied version.
