Waterproof DMX RGBW Pixel LED Strip
Waterproof DMX LED Pixel Strip With 5050 Addressable Rgb Rgbw 4 Chips In 1
Individually addressable full-color LED strip for pixel-mapped accent, contour and signage runs.
- Certification
- CE · ROHS · BIS
- MOQ
- 1 piece
- Delivery
- 5–7 days
- Warranty
- 2 years
Reply within 8 hours · Free sample for qualified projects
Overview
About the Waterproof DMX RGBW Pixel LED Strip
Waterproof DMX RGBW Pixel LED Strip is an addressable full-color LED strip built on SMD 5050 emitters at 60LEDs/M. Each LED is individually addressable, so the strip drives pixel-mapped wash, chase and contour effects.
Control is over standard SPI. It runs on DC 12V. A 120° beam angle gives an even spread across the run.
It ships in IP20/IP65/IP67/IP68 and links end-to-end for longer runs.
Highlighted features
- Individually addressable pixels for full pixel-mapping and video effects
- Smooth colour mixing and dimming
- IP20/IP65/IP67/IP68 sealing for outdoor and wet-location use
- Cuttable and end-to-end linkable
- 120° beam angle for even, wide coverage
Technical parameters
- Beam Angle
- 120°
- CRI
- 80">Ra>80
- Cuttable
- 10CM
- IP Rating
- IP20/IP65/IP67/IP68
- LED Quantity
- 60LEDs/M
- LED Type
- SMD 5050
- Lumen
- 14-16lm/LED
- PCB Color
- White PCB, Black PCB
- Power
- 14.4W/M
- Size
- 5000*10mm
- Voltage
- DC 12V
- Working Temperature
- -20℃~50℃
- LED Chip
- SMD5050 RGBW LED chip
- IC Chip
- DMX512 UCS512 WS512 TM512
- Input Voltage
- DC12V
- Watts
- 14.4W/M
- IP Rate
- IP20(non-waterproof), IP65(Silicon-tube waterproof)
Model DMX RGBW — configurable per order. Request the full datasheet.
- Payment
- T/T
- Supply
- Large factory stock
- Origin
- Shenzhen, China
- OEM / ODM
- Welcome
Built for these venues.
OEM & ODM — built to your spec.
Cut-to-length: fixtures are built to the run length your project needs.
Driver IC selection to match your controller ecosystem.
Control protocol configurable to your rig.
Ingress protection: IP20/IP65/IP67/IP68.
